Lenovo CC100
Commercial walkie-talkie
- 16 Channels
- 2600 mAh battery capacity
- Rugged Body
- Voice Prompt
- PTT call function
- Clearand loud voice
- Low Battery warning
- Easy to carry
Application Scenario
- Security
- Construction site
- KTV
- Hotel
- Market
- Residential
- Wharf
General Indicators
| Frequency Range |
UHF:446.00-446.200MHz |
| Channel Capacity |
16 |
| PLL Channel spacing |
12.5kHz |
| Battery Voltage |
3.7V |
| Weight (With Battery
and Antenna) |
20 |
| Dimensions |
178X59X31.5mm (Without
Antenna) |
| Battery Capacity |
2600mAh |
Receiver
| Receiver Sensitivity |
≤0.25uV |
| Adjacent Channel
Selectivity |
≥60dB |
| Blocking |
≥80dB |
| FM HAM & Noise |
25K≥45dB 12.5K≥40dB |
| Receive Audio Power |
1 W |
| Audio Distortion |
≤5% |
| Inter Modulation |
60 dB |
Transmitter
| Modulation Type |
16kϕF3E/8kϕF3E |
| Modulation Limit |
±5kHz/±2.5kHz |
| RF Output Power |
0.5W |
| Residual FM |
-45 dB |
| Adjacent Channel Power |
-67dB |
| Radiated Emission |
-36 dBm |
Environmental Indicators
| Operating Temperature |
-20°C ~ +60°C |
| Storage Temperature |
-20°C ~ +70°C |
| Shock and Vibration |
According GJB 150-2009 and
MIL-STD-810
C/D/E/F/G Standard. |
Note: The above Specifications are tested in accordance with the TIA/EIA-603 standard. Due to the
continuous updating of the technology, the above indicator data will be changed with out notice.
